Durable! Effective weighing technology for construction material and mineral industry
Weighing chemical substances requires precise measurement results - for quality but also for safety reasons. If these two topics are also high on the relevance agenda in your company, we can do a lot for you with our weighing technology.
The reliable Weigh Cells, heavy-duty checkweighers and catchweighers from Wipotec accurately check your products for the correct weight. Large packs and containers are also weighed – at consistent high-belt speeds. Our high-tech weighing technology allows you to undertake up to 100 weighing operations per minute even in heavy-duty operation. The modular machines are easy to integrate into your production and packaging lines and provide complete documentation of your production data for optimal quality control.
Find out more about the range of applications of Wipotec weighing technology in the construction material and mineral industry or find the right machine for your individual application now!
- Reliable dynamic weighing of large, heavy products
- High throughputs
- Flexible integration in existing production lines
Our Weigh Cell Technology: Small and Compact
The fact that we have designed the Weigh Cells to be small and compact as sensor components allows them to be used as a Modular Multilane System and guarantees you maximum flexibility.
A further advantage: Thanks to specially designed Weigh Cells, we can also integrate them in production environments of zone 2 (gas) and zone 22 (environments with non-conductive dust). The special feature here is that both integration and maintenance are equally trouble-free. A docking station allows your engineers and service teams to remove the Weigh Cell for maintenance and cleaning work and replace it just as easily.
Connection of our Weigh Cells to the control system of your process is equally straightforward: as a ready-for-connection installation component, the Weigh Cell delivers final weight values via a CAN bus as standard immediately after commissioning. Special environmental parameters have to be taken into account in your production, these can be configured via integrated software filters and, of course, adapted according to your own specifications.
Our EX-protected Weigh Cells of type SW-D-FS-EX, specially developed for sensitive use in chemical environments, weigh your substances up to a weight of 2000 g safely and with high performance. The system's active inherent damping guarantees you the shortest possible measuring times with parallel high resolution - aspects that have a positive effect on the quality and safety of your processes.
Keyword safety: We meet your high safety requirements via the ignition protection types II 3 G Ex nA IIB T4 and II 3 D Ex tD IP54 100 °C.
Checkweighers from Wipotec: Always the correct weight!
Sacks of cement and buckets of paint are also subject to the pre-package directive. According to this regulation the weight filled must be within close limits of the nominal weight. Compliance with this directive offers beneficial rewards including customer satisfaction and sustained profitability by avoiding excessive overfill.
Our checkweighers provide continuous, precise measurement and documentation of your completely packaged products. Packages with a filling quantity that is above or below the stipulated limits are removed from the product flow by various sorting functions. For complete line optimisation, our feedback control feature improves line efficiency. Products are also weighed accurately in testing working environments using Active Vibration Compensation (AVC). AVC filters all shocks and vibrations to provide 100% accurate results.
Heavy-duty weighers for large calibre
Our robust heavy-duty checkweighers from Wipotec can also cope with high weights. Depending on needs, the gross weighing range is up to 120 kg (optionally: 150 kg). Large belt widths of up to 700 mm, as well as individual operating heights ensure the safe transport of sacks, boxes and buckets. The maintenance-free drive motors transport your products through the weighing process. The appropriate sorting device removes even the heaviest of products, with the incorrect weight, from the product flow Our fully automatic heavy-duty weighers offer throughputs of up to 100 pieces per minutes with measurements to the gram.
The right combination
Irrespective of whether the product is wall paint or bulk material such as cement or filler, the exact combination must be correct. Our weighing technology is easy to use as a batch weighing system. The correct mixture of several components is easy to check using the reliable scales at the individual filling stations. All of these machines are equipped with the right degree of protection, to avoid unwanted damage, and are easy to clean.
Flexible integration into your production line
Our modular weighing solutions integrate perfectly into your existing production line whilst meeting your specific requirements. Our sales and project teams support you during the configuration of the solution according to your individual requirements and ensure quick and efficient installation.
Our team supports you in the installation and integration of the machines into your production line and accompanies the synchronisation to higher-level systems competently and reliably. Wipotec is certified according to ISO 9001 and is also authorised to carry out the conformity assessment according to Module D of the "Measuring Instruments Directive" (MID) in accordance with Directive 2014/32/EU itself (formerly manufacturer's verification).
High degree of user-friendliness and comprehensive analyses
The intuitive touch screen user-interface is easy to use in order to minimise mistakes during production. Moreover, changeover times are significantly reduced; new production orders can be swiftly initiated. The relevant production data such as weight, quantity and ejected products are completely acquired and can be displayed in a clear manner.
A main factor in increasing production efficiency is a regular and exact analysis of relevant data. Our optional ComScale4 software is a web-based, network-enabled software for the capture and analysis of production data. It connects any number of checkweighers, across different sites, with other inspection machines (X-ray scanner, metal detectors). Due to its web based architecture Comscale4 can be used from a PC, tablet or smartphone. You can also amend parameters such as changing the product, given corresponding permissions. The relevant data is structured and displayed directly on the machines via the standard interfaces, as well as via the network.
You can evaluate the data using the statistics functions, prepare graphs and inform your partners and colleagues using statistics saved in standard file formats., Therefore, there is always complete transparency in your production.
Find the right solution for your application now!
